Here are the core specs for the BOY 50 T2 (older hydraulic 50-ton class machine with Dipronic controls). Specs vary a bit by year and screw option, but this is the standard range you’ll see:
🔧 BOY 50 T2 – Key Specifications
🏋️ Clamping Unit
Clamping force: 50 tons (500 kN)
Tie bar spacing: ~305 × 305 mm (≈ 12″ × 12″)
Platen size: ~500 × 500 mm (≈ 19.7″ × 19.7″)
Opening stroke: ~350 mm (13.8″)
Max daylight: ~600 mm (23.6″)
Min mold height: ~250 mm (9.8″)
Ejector stroke: ~80 mm
💉 Injection Unit
Screw diameter: typically 38 mm (options 28–42 mm on series)
Shot size:
~96–136 cm³
~115–121 g (PS)
Injection pressure: ~1340–1360 bar
Injection stroke: ~120 mm
Screw speed: ~10–320 rpm
⚡ Power & Hydraulics
Pump motor: ~11 kW
Heating capacity: ~6 kW
Oil tank capacity: ~250 liters
📏 Size & Weight
Machine dimensions: ~3.3–3.6 m L × 1.0–1.2 m W × 1.7–1.8 m H
Weight: ~2,000–2,300 kg (≈ 4,400–5,000 lbs)
⚙️ General Notes
Hydraulic 3-platen design
Dipronic control (older generation)
Shot capacity range roughly 2–5 oz depending on screw
Known for large mold area for its tonnage + compact footprint
